Honda GX200 – 6.5HP 196cc Horizontal Engine
In Stock
Power your professional equipment with the 6.5HP 196cc Honda GX200 Engine, featuring a commercial-grade horizontal shaft and OHV design for high-torque performance in construction and karting.
- Power: 6.5 Net HP 196cc
- Design: Professional OHV Single Cylinder
- Durability: Precision Cast Iron Sleeve
- Shaft: 3/4 Inch Keyed Horizontal
- Warranty: Three Year Commercial Warranty
Description
Honda GX200 QX2 Horizontal Engine
Honda GX200 QX2 (GX200UT2QX2) horizontal OHV engine is 200cc and puts out 5.5 net HP. This Honda GX has a 3/4″ x 2-7/16″ crankshaft. The engine has a recoil starter and includes a standard muffler and oil alert system.
| BRAND | Honda |
|---|---|
| MODEL NUMBER | GX200-QX2 |
| REPLACES MODELS | GX200QX2, GX200 QX2, GX200T1QX2, GX200UT1-QX2, GX200UT2-QX2, GX200UT2QX2, GX200K1QX2, GX200K1-QX2, GX200QX2, GX200-UT1-QX2, GX200-T1-QX2, GX200-UT1-QX2, GX200QX2 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 41 |
| DISPLACEMENT | 196cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Horizontal |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 3/4″ x 2-27/64″ |
| CRANKSHAFT DIAMETER | 3/4″ |
| CRANKSHAFT LENGTH | 2-27/64″ |
| CRANKSHAFT END TAPPED SIZE | 5/16 – 24 |
| CRANKSHAFT KEYWAY WIDTH | 3/16″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron |
| AIR CLEANER TYPE | Dual Element Silent |
| FUEL PUMP | No |
| OIL COOLER | No |
| OIL CAPACITY | 20 |
| LOW OIL ALERT | No |
| LOW OIL SHUTDOWN | Yes |
| IGNITION SYSTEM | Transistorized Magneto |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Manual |
| BOLT CIRCLE | 3 – 5/8 |
| PTO HEIGHT | 4 – 11/64 |
Honda GX200 Specs
| Brand | Honda |
| Full Model Code | GX200UT2 |
| Country of Origin | Thailand |
| Engine Series | Commercial GX |
| Engine Type | 4-Stroke, OHV, Single Cylinder |
| Displacement | 196 cc |
| Net Power Output | 5.5 HP (4.1 kW) @ 3600 RPM |
| Net Torque | 12.4 Nm @ 2500 RPM |
| Bore x Stroke | 68.0 x 54.0 mm |
| Compression Ratio | 8.5:1 |
| Cooling System | Forced Air |
| Ignition System | Transistorized Magneto |
| Starting System | Recoil Start |
| Fuel Tank Capacity | 3.1 L |
| Fuel Consumption | 1.7 L/h |
| Oil Capacity & Type | 0.6 L (SAE 10W-30) |
| PTO Shaft Type | 3/4 inch Keyed Straight |
| Dry Weight | 16.1 kg |
| Dimensions | 321x376x346 mm |
| Application | Pressure washers, generators, and agricultural equipment. |
