Miller 907719 Dynasty 800 High-Output AC/DC TIG/Stick Welder
$13,476.00
In Stock
In Stock
Wholesale Price
Request for Quotations
Description
Miller Dynasty 800 Tig Welder 907719 Specs
- Brand: Miller
- Model: Dynasty 800
- MPN: 907719
- Processes: TIG (GTAW), Stick (SMAW)
- Input Voltage: 208–575 V, 3-Phase, Auto-Line
- Output Range: 5 – 800 Amps
- Duty Cycle: 100% @ 800A (480V)
- AC Waveforms: Advanced Squarewave, Soft Squarewave, Sinewave, Triangular
- AC Balance Control: Adjustable 60–90% EN
- AC Frequency Control: 20–400 Hz
- Independent Amperage Control: Yes (EP and EN independently adjustable)
- Memory Settings: Yes, with program storage
- Dimensions: 17 in H x 14.25 in W x 28 in D (432 mm x 362 mm x 711 mm)
- Net Weight: 185 lb (83.9 kg)
- Power Source Type: Inverter
- Technology: Auto-Line, Fan-On-Demand, Cooler Power Supply (CPS) Compatible
- Applications: Heavy Fabrication, Aerospace, Pipe Welding, Shipbuilding, Manufacturing
- Weldable Materials: Aluminum, Stainless Steel, Carbon Steel, Titanium
- Warranty: 3-Year Miller True Blue Warranty
- Condition: New
- Google Product Category: 2920 (Welding Machines)
Miller Dynasty 800 High-Output AC/DC TIG/Stick Welder Technical Specifications
| Brand | Miller |
|---|---|
| Full Model Name/SKU | Dynasty 800 High-Output Base (907719) |
| Country of Origin | USA |
| Welding Process | AC/DC TIG, Pulsed TIG, Stick, Air Carbon Arc Gouging |
| Inverter/Transformer Technology | High-Output AC/DC IGBT Inverter |
| Input Voltage | 208 – 575 V (Three-Phase Only) |
| Output Current Range | 5 – 800 A |
| Duty Cycle | 100% @ 600 A, 60% @ 800 A |
| Open Circuit Voltage (OCV) | 75 VDC |
| Rated Input Capacity | 32 kVA |
| Power Factor & Efficiency | 88% Efficiency / 0.95 Power Factor |
| Wire Feed Speed Range | N/A |
| Protection Class | IP23 |
| Insulation Class | Class H |
| Cooling System | Fan-On-Demand (Air-Cooled Power Source) |
| Dimensions | 880 x 349 x 559 mm |
| Net Weight | 89.8 kg |
| Smart Features | Extended Pulse Frequency (up to 5000 PPS), Pro-Set, Programmable Waveforms |
| Standard Compliance | CSA, CE, IEC 60974-1 |
| Primary Application | Heavy Industrial Manufacturing, Large Mold Repair, Specialized High-Current Alloys |
