NorthStar 30-Ton Log Splitter H/V 203cc Kohler CH270 Engine

$250.00
In Stock
In Stock
Wholesale Price
Request for Quotations
SKU: CH270
Category:
Brand:

Description

This NorthStar Horizontal/Vertical Log Splitter’s multi-patented design gives you premium components and exclusive features that let you save time, increase performance and work effectively. You can count on NorthStar to bring strength, durability and innovation every time. The backbone of this log splitter is an industrial-strength I-beam with heavy plate steel reinforcement. The patented wedge design, made with alloy steel, maintains consistent split and has a unique curve that reduces initial contact area for maximum penetrating force. Add the optional NorthStar Wedge Wings (Item# 110910, sold separately) to make each stroke more efficient. Auto-return wedge saves time and effort when splitting.The premium hydraulic system is protected by a quad filtering system that uses four different components to protect the hydraulic system from contaminants. Large hydraulic oil reservoir allows fluid to cool, reducing wear and allowing fluid to last longer. Slide-action self-leveling pivot makes it simple to switch between horizontal and vertical split. Designed to be easy to use in both orientations. Some assembly required.What’s Included

    (1) NorthStar Horizontal/Vertical Log Splitter
Item# 1131
Brand NorthStar
Manufacturer’s Warranty 4 year limited warranty
Ship Weight 747.0 lbs
Product Type Horizontal/vertical splitter
Ram Force (Tons) 37
Max. Log Size L x W (in.) 25 x 16
Continuous Force (Tons) 34.3
Engine Honda GX270
Engine Displacement 270
Gross Torque 13.1 ft.-lbs. at 2,500 RPM
Low Oil Shutdown Yes
Wedge 8 1/2 in.H
Cycle Time (sec.) 14
Automatic Cylinder Return Yes
Cylinder 5 in. x 24 in.
Pump 16 GPM
Max. PSI 3,500
Oil Reservoir (gal.) 9
Fuel Capacity (gal.) 1.4
Hoses High pressure w/wire braid
Log Cradle Yes
Log Lift No
Jack Stand Yes
Ball Coupler (in.) 2
Tire Size 8 in.
Lights No
Fenders Included
Pre-assembled Assembly required
Dimensions L x W x H (in.) 90 x 45 x 45

Kohler CH270 Command PRO - 7HP 208cc Horizontal Specs

BrandKohler
Full Model CodeCH270-3111
Country of OriginChina
Engine Series/FamilyCommand PRO
Engine TypeAir-cooled 4-stroke OHV cylinder
Displacement208 cc
Net Power Output7.0 HP (5.2 kW) @ 3,600 rpm
Max. Net Torque13.8 Nm (10.2 lbs-ft) @ 2,400 rpm
Bore x Stroke70 x 54 mm
Compression Ratio8.5:1
Cooling SystemForced Air
Ignition SystemElectronic Magneto
Starting SystemRecoil Starter (Quad-Clean)
Fuel Tank Capacity4.0 Liters
Fuel Consumption1.7 L/h @ 3,600 rpm
Oil Capacity & Grade0.6 L (SAE 10W-30)
PTO Shaft RotationCounterclockwise
Dry Weight17.5 kg (38.5 lbs)
Dimensions323 x 385 x 361 mm
ApplicationPressure washers, tillers, and chippers.
