Vestil BTA-20006048 20,000 lbs Aluminum Dockboard (60 in W x 48 in L)
Command extreme capacity and unwavering reliability with the Vestil BTA-20006048, a massive 20,000 lbs Aluminum Dockboard (60 in W x 48 in L). This fixed dockboard is engineered for the heaviest forklift traffic and concentrated loads, guaranteeing superior structural integrity and safety for the most demanding loading environments. The Vestil BTA-20006048 is an indispensable, heavy-duty investment in dock safety; check out our Big Foot Stabilizing Jack for maximum trailer stability.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operations. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at least four times the lifting capacity of fork truck. The width of the dockboard should be at least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 60 X 48 and usable dimenions of 53-3/4 X 48. This dockboard is rated at a 20000 lbs. capacity.
| Item# | 4219755 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 206.0 lbs |
| Capacity | 20,000 lb |
| Ramp Length | 48 in |
| Ramp Width | 60 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.5 in |
| Left Leg Height | 8 in |
| Right Leg Height | 9 in |
| Height Difference | 5.5 in |
| Usable Ramp Length | 48 in |
| Usable Ramp Width | 53.75 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 206.0000 lb |
| Dimensions L x W x H (in.) | 48.0 x 60.0 x 11.625 in |
Vestil BTA-20006048 20,000 lbs Aluminum Dockboard (60 in W x 48 in L) Specs
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 206.0 lbs |
| Capacity | 20,000 lb |
| Ramp Length | 48 in |
| Ramp Width | 60 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.5 in |
| Left Leg Height | 8 in |
| Right Leg Height | 9 in |
| Height Difference | 5.5 in |
| Usable Ramp Length | 48 in |
| Usable Ramp Width | 53.75 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 206.0000 lb |
| Dimensions L x W x H (in.) | 48.0 x 60.0 x 11.625 in |
