Vestil BTA-20006072 20K Aluminum Dockboard (60in. Wide x 72in. Long)
Vestil BTA-20006072 20K Aluminum Dockboard features a 20,000lb capacity with a 60-inch width and 72-inch length, optimized for narrow docks and heavy loads.
- Industrial 20,000lb Rating: High-strength aluminum construction handles the heaviest industrial inventory and machinery.
- Extended 72″ Length: Provides a shallower incline for docks with significant height differentials to the trailer.
- Narrow 60″ Width: Fits tight dock configurations while providing maximum weight support for heavy equipment.
- Safety Side Rails: Painted high-visibility yellow to guide operators and ensure safe transit across the bridge.
- Corrosion-Resistant Build: Durable aluminum resists rust and environmental wear, ensuring long-term reliability.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operat aions. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at a least four times the lifting capacity of fork truck. The width of the dockboard should be at a least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 60 X 72 and usable dimenions of 54-1/4 X 71-3/4. This dockboard is rated at a 20000 lbs. capacity.
| Item# | 4220473 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 357.0 lbs |
| Capacity | 20,000 lb |
| Ramp Length | 72 in |
| Ramp Width | 60 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.625 in |
| Left Leg Height | 12 in |
| Right Leg Height | 14 in |
| Height Difference | 8.5 in |
| Usable Ramp Length | 71.75 in |
| Usable Ramp Width | 54.25 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 357.0000 lb |
| Dimensions L x W x H (in.) | 72.0 x 60.0 x 18.9063 in |
