Rolair H10312K60 Air Compressor – 10HP 120Gal
In Stock
$2,634.00
In Stock
Rolair H10312K60 Air Compressor is a 10 HP electric-powered 175 PSI stationary system with a 120-gallon horizontal tank for high-capacity three-phase industrial air requirements.
Rapid Air Displacement: Supplies 34 CFM @175PSI.
Horizontal Storage Tank: Offers massive air reservoir.
Heavy Cast Iron: Promotes superior heat dissipation.
Three Phase Support: Runs on 230V.
Industrial Production Focus: Powers continuous machinery lines.
Description
Rolair H10312K60 10HP 120 Gallon Horizontal Compressor
The Rolair H10312K60 is a premier two-stage industrial compressor engineered for maximum stability and high-volume air delivery in heavy manufacturing settings. Driven by a 10HP three-phase motor on a horizontal 120-gallon ASME tank, it delivers a robust 34.4 CFM at 175 PSI. It is specifically designed for facilities requiring a constant air supply for automated machines and high-demand assembly lines.
Mechanical longevity is maintained through the K60 pump featuring Swedish lamellar reed valves and automotive-style bearing inserts on the connecting rods. Selecting industrial reciprocating air compressors like the H10312K60 provides a rugged 1740 RPM motor and a splash-lubrication system designed to withstand the grueling duty cycles of a professional industrial or high-production manufacturing environment.
Rolair H10312K60 Key Features
- Tank Size: 120 Gallon Horizontal
- Lubrication: Splash Lubricant System
- Starting System: Automatic Unloading Device
- Fuel System: 208/230/460V Three Phase
- Max Pressure: 175 PSI Rating
- Air Displacement: 34.4 CFM Delivery
- Warranty: 1 Year Limited
Engineered for Production Stability
The unit features a heavy-duty two-stage pump with a large cooling flywheel to maintain low pump temperatures during continuous operation. The horizontal 120-gallon ASME tank is manufactured to meet strict National Board certification standards for high-pressure safety. It includes a multiple V-belt drive for efficient power transfer and a totally enclosed steel belt guard for operator protection.
Industrial Fleet and Production
Ideally suited for fleet maintenance bays, large-scale automotive service centers, and industrial woodworking shops, this model provides a dependable stationary air source. The 120-gallon reserve acts as a significant buffer, reducing motor wear and preventing pressure drops during peak demand periods. Facility managers appreciate the H10312K60 for its legendary durability and high-volume pneumatic output.
Equip your facility with the heavy-duty horizontal power and high-volume reliability of the Rolair H10312K60 industrial compressor. Contact our technical team to Request Technical Quote or Check Availability at Muldepot.com.
Rolair H10312K60 Air Compressor Specs
| Brand | Rolair |
| Full Model Code | H10312K60 |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Two-Stage / Heavy-Duty) |
| Lubrication Style | Splash Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 10 HP |
| Max Working Pressure | 175 Psi |
| Free Air Delivery / Capacity | 34.0 CFM @ 175 Psi |
| Drive Type | Belt Drive (Electric) |
| Noise Level | 84-88 dB(A) |
| Outlet Connection Size | 1 Inch NPT |
| Tank Volume | 120 Gallons (Horizontal) |
| Dimension (LxWxH) | 1727 x 711 x 1168 mm |
| Net Weight | 360 kg |
| Control Panel Type | Magnetic Starter Included |
| Voltage/Phase/Frequency | 460V / 3 Phase / 60 Hz |
| Standard Warranty | 1 Year Limited |
| Maintenance Interval | 500 Hours |
| Application | High-reliability industrial plants requiring 460V electrical efficiency and robust horizontal air storage. |
