Rolair H10360K60 Air Compressor – 10HP 60Gal
High Volume Airflow: Delivers 34 CFM @175PSI.
Horizontal Tank Design: Provides stable low-profile mounting.
Rugged Iron Pump: Ensures maximum mechanical reliability.
Three Phase Source: Operates on 230V.
Industrial Production Focus: Powers continuous machinery lines.
Description
Rolair H10360K60 10HP 60 Gallon Three Phase Compressor
The Rolair H10360K60 is a high-output two-stage industrial compressor designed for stationary shop applications where maximum airflow is required in a compact horizontal footprint. Featuring a 10HP three-phase motor and the upgraded K60 pump, this unit delivers a formidable 34.4 CFM at 175 PSI, making it a favorite for automotive service centers running multiple heavy tools.
Mechanical integrity is ensured by a cast-iron pump with an aluminum head for rapid heat dissipation and Swedish lamellar reed valves for maximum thermal efficiency. Utilizing industrial reciprocating air compressors like the H10360K60 guarantees superior volumetric performance, while the automatic unloading device allows for smooth, loadless starts to protect the internal electrical components.
Rolair H10360K60 Key Features
- Tank Size: 60 Gallon Horizontal
- Lubrication: Splash Lubrication System
- Starting System: Loadless Auto-Start
- Fuel System: 208/230/460V Three Phase
- Max Pressure: 175 PSI Rating
- Air Displacement: 34.4 CFM Delivery
- Warranty: 1 Year Unit
High-Volume Production Build
The unit features a 100% cast-iron cylinder pump housing and an industrial-grade motor designed for constant duty cycles. It includes a totally enclosed steel belt guard, a heavy-duty brass shut-off valve, and an ASME-certified 60-gallon tank. The K60 pump’s four-cylinder design provides superior balance and reduced vibration during continuous duty operations in high-demand shop environments.
Automotive Service and Fabrication
Ideally suited for multi-bay automotive service and custom metal fabrication, this model provides the airflow needed for high-pressure pneumatic tools without a massive footprint. The 10HP motor ensures rapid recovery times, maintaining peak pressure even during intensive work periods. Technicians value the H10360K60 for its rugged durability and the consistent high-pressure output provided by the K60 pump.
Deploy the Rolair H10360K60 to maximize your pneumatic power with a compact and efficient 10HP air source. Contact our technical team to Request Technical Quote or Check Availability at Muldepot.com.
Rolair H10360K60 Air Compressor Specs
| Brand | Rolair |
| Full Model Code | H10360K60 |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Two-Stage) |
| Lubrication Style | Splash Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 10 HP |
| Max Working Pressure | 175 Psi |
| Free Air Delivery / Capacity | 34.0 CFM @ 175 Psi |
| Drive Type | Belt Drive (Electric) |
| Noise Level | 84-88 dB(A) |
| Outlet Connection Size | 1 Inch NPT |
| Tank Volume | 60 Gallons (Horizontal) |
| Dimension (LxWxH) | 1168 x 610 x 1067 mm |
| Net Weight | 255 kg |
| Control Panel Type | Magnetic Starter Included |
| Voltage/Phase/Frequency | 460V / 3 Phase / 60 Hz |
| Standard Warranty | 1 Year Limited |
| Maintenance Interval | 500 Hours |
| Application | Primary air supply for industrial manufacturing facilities requiring high-pressure 460V electrical efficiency. |
