Quincy 253DS80HCB20 Air Compressor – 5HP 80Gal
In Stock
$1,920.00
In Stock
Quincy 253DS80HCB20 Air Compressor – 5HP 80Gal This professional 5 HP duplex unit utilizes a massive horizontal configuration designed to provide reliable pneumatic volume for critical medical and industrial facility infrastructures.
Redundant Power System: Dual high performance motor units
Horizontal Receiver Design: Features 80 gallon stationary tank
Low Voltage Phase: Requires 200V three phase power
Maximum Working Pressure: Stable 175 PSI delivery output
Industrial Tool Reliability: Engineered for continuous heavy duty
Quincy 253DS80HCB20 Air Compressor Specs
| Brand | Quincy |
| Full Model Code | 253DS80HCB20 (QT-5 Series) |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Two-Stage) |
| Lubrication Style | Splash Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 5 HP |
| Max Working Pressure | 175 Psi |
| Free Air Delivery / Capacity | 17.2 CFM @ 175 Psi |
| Drive Type | Belt Drive (Electric) |
| Noise Level | 76-80 dB(A) |
| Outlet Connection Size | 1/2 Inch NPT |
| Tank Volume | 80 Gallons (Horizontal) |
| Dimension (LxWxH) | 1372 x 559 x 1041 mm |
| Net Weight | 235 kg |
| Control Panel Type | Magnetic Starter Mounted |
| Voltage/Phase/Frequency | 200-208V / 3 Phase / 60 Hz |
| Standard Warranty | 1 Year (Extended to 3Y with Kit) |
| Maintenance Interval | 1000 Hours (Synthetics) |
| Application | Commercial automotive shops and industrial fabrication facilities requiring heavy-duty 3-phase air. |
