Kohler CH640 Command PRO – 12HP Horizontal Engine
In Stock
$913.00
In Stock
Experience high-efficiency mechanical drive with the Kohler CH640 Command PRO featuring a 12HP horizontal configuration optimized for professional-grade industrial applications.
- Output: 674cc V-Twin Horizontal Engine
- Filtration: Heavy Duty Air Cleaner
- Lubrication: Full Pressure Oil System
- Durability: Cast Iron Cylinder Sleeves
- Warranty: Three Year Professional Warranty
Description
Professional Coffee Equipment
Kohler CH640 3204 Horizontal Engine
The Kohler CH640 3204 is a 643cc, V-twin, air-cooled, 4-stroke, horizontal-shaft engine designed for heavy-duty commercial and industrial applications. Delivering 20 horsepower, it is commonly used in equipment like lawn mowers, generators, and construction machinery.| BRAND | Kohler |
|---|---|
| MODEL NUMBER | CH640-3204 |
| REPLACES MODELS | PA-CH640-3006, CH640-3006 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 107 |
| DISPLACEMENT | 674cc |
| STARTER TYPE | Electric |
| CRANKSHAFT ORIENTATION | Horizontal |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 1-7/16" x 4.46" |
| CRANKSHAFT DIAMETER | 1-7/16" |
| CRANKSHAFT LENGTH | 4.46" |
| CRANKSHAFT END TAPPED SIZE | 5/8 -18 |
| CRANKSHAFT KEYWAY WIDTH | 3/8" |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| CYLINDERS | 2 |
| CYLINDER BORE TYPE | Cast Iron |
| AIR CLEANER TYPE | Large Capacity Dual Element |
| FUEL PUMP | Yes |
| OIL COOLER | No |
| OIL CAPACITY | 60 |
| LOW OIL ALERT | No |
| LOW OIL SHUTDOWN | No |
| IGNITION SYSTEM | Electronic |
| CARBURETOR TYPE | Smart-Choke |
| CHOKE CONTROL | Remote |
| BOLT CIRCLE | 5-5/8; 7-3/4 |
| PTO HEIGHT | 6 - 1/8 |
