Vestil BTA-12007866 12K Aluminum Dockboard (78in. Wide x 66in. Long)
Vestil BTA-12007866 12K Aluminum Dockboard delivers a 12,000lb capacity in a 78-inch wide by 66-inch long size for professional freight loading.
- Industrial 12,000lb Rating: Robust construction supports the weight of standard and heavy-duty forklifts.
- Standard 78″ Width: Accommodates standard trailers with ease while providing ample wheel clearance.
- Yellow Safety Rails: High-visibility curbs prevent accidents and reinforce the aluminum plate.
- Integrated Safety Legs: Keeps the board securely anchored to the dock for maximum safety.
- Beveled Transitions: Designed for smooth wheel roll-over to protect cargo and equipment.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operations. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at least four times the lifting capacity of fork truck. The width of the dockboard should be at least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 78 X 66 and usable dimenions of 71-1/2 X 66. This dockboard is rated at a 12000 lbs. capacity.
| Item# | 4221054 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 352.0 lbs |
| Capacity | 12,000 lb |
| Ramp Length | 66 in |
| Ramp Width | 78 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.5 in |
| Left Leg Height | 12 in |
| Right Leg Height | 14 in |
| Height Difference | 8 in |
| Usable Ramp Length | 66 in |
| Usable Ramp Width | 71.5 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 352.0000 lb |
| Dimensions L x W x H (in.) | 66.0 x 78.0 x 15.625 in |
