Vestil BTA-09007236 9K Aluminum Dockboard (72in. Wide x 36in. Long)
Vestil BTA-09007236 9K Aluminum Dockboard offers a 9,000lb capacity with dimensions of 72 inches wide by 36 inches long, ideal for standard short gaps.
- Heavy-Duty 9,000lb Capacity: Engineered to support high-capacity pallet jacks and warehouse freight.
- Balanced 72″ Width: A versatile path that fits most standard dock and trailer openings.
- Safety Locking Legs: Anchors the board firmly to prevent sliding during heavy-load cycles.
- Aluminum Tread Plate: Provides a non-slip surface and long-term resistance to corrosion.
- High-Visibility Curbs: Painted yellow to guide traffic and prevent accidental run-offs.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operations. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at least four times the lifting capacity of fork truck. The width of the dockboard should be at least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 72 X 36 and usable dimenions of 67-1/2 X 36. This dockboard is rated at a 9000 lbs. capacity.
| Item# | 4221601 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 111.0 lbs |
| Capacity | 9,000 lb |
| Ramp Length | 36 in |
| Ramp Width | 72 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.375 in |
| Left Leg Height | 8 in |
| Right Leg Height | 9 in |
| Height Difference | 4 in |
| Usable Ramp Length | 36 in |
| Usable Ramp Width | 67.5 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 111.0000 lb |
| Dimensions L x W x H (in.) | 36.0 x 72.0 x 11.75 in |
