Vestil BTA-07006672 7K Aluminum Dockboard (66in. Wide x 72in. Long)
In Stock
$1,813.00
In Stock
Vestil BTA-07006672 7K Aluminum Dockboard delivers a 7,000lb capacity in a 66-inch wide by 72-inch long configuration, ideal for mid-sized equipment in long-reach applications.
- Professional 7,000lb Rating: Engineered for safe and efficient transport of warehouse freight and equipment.
- Extended 72″ Reach: Minimizes the slope for safer manual pushing and pulling of heavy pallet loads.
- Concise 66″ Width: Perfect for facilities with restricted dock widths requiring a long-reach bridge.
- Integrated Safety Legs: Prevents the board from shifting or walking during high-intensity loading.
- Beveled Entry/Exit: Smoothes the path for small wheels on dollies and manual pallet trucks.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operations. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at least four times the lifting capacity of fork truck. The width of the dockboard should be at least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 66 X 72 and usable dimenions of 61-1/2 X 72. This dockboard is rated at a 7000 lbs. capacity.
| Item# | 4223341 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 292.0 lbs |
| Capacity | 7,000 lb |
| Ramp Length | 72 in |
| Ramp Width | 66 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.5 in |
| Left Leg Height | 12 in |
| Right Leg Height | 14 in |
| Height Difference | 8.5 in |
| Usable Ramp Length | 72 in |
| Usable Ramp Width | 61.5 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 199.0000 lb |
| Dimensions L x W x H (in.) | 72.0 x 66.0 x 16.75 in |
