Vestil BTA-06007248 6K Aluminum Dockboard (72in. Wide x 48in. Long)
Vestil BTA-06007248 bridges broad multi-pallet warehouse transit via an extra-wide aluminum industrial plate assembly engineered to support heavy forklift traffic safely.
- Substantial 6,000 lb capacity carries heavy payloads
- Long 48 in ramp length softens inclines
- Thick 0.313 in dock thickness prevents warping
- Solid aluminum curb material prevents accidental runoffs
- Official OSHA approved construction ensures field compliance
Description
Vestil BTA-06007248 Aluminum Dockboard
Vestil BTA-06007248 portable truck dockboard completely addresses variable dock height alignment gaps facing industrial plant managers trying to secure material handling zones across wide terminal bays. The specialized uneven locking leg configuration features 8-inch and 9-inch structures that allow the platform to sit canted when idle on concrete surfaces, permitting uncompromised forklift tine pick accessibility. Shipping crews comfortably accelerate daily freight sorting schedules because smooth beveled outer edge boundaries drop machinery wheel resistance to limit trailer edge tire wear.
Fabricated proudly in strict compliance with national OSHA safety regulations, this 130-pound structural aluminum bridge handles a 6,000-pound load rating reliably over extensive facility service cycles. The 72-inch wide by 48-inch long flatbed deck features all-welded high-visibility aluminum safety curbs to prevent accidental runoff deviations. Spanning 48 by 72 by 11.75 inches overall with a 0.313-inch deck thickness, this durable material handling platform secures enterprise warehouse logistics under a 3 month limited warranty.
Performance Metrics and Technical Data
- Delivers professional 6,000 pound load bridging capabilities
- Spans extensive forty eight inch structural ramp lengths
- Maintains maximum clearance via seventy two inch wide decks
- Provides functional 67.5 inch wide usable lane access
- Fabricated from heavy 0.313 inch thick diamond treadplates
- Features integrated 5.5 inch maximum structural height differences
- Includes welded aluminum curbs to safeguard vehicle tires
- Weighs 130 pounds for balanced facility support installation
- Requires 130 pounds total shipping freight logistics distribution
- Guaranteed by standard three month limited product warranties
Vestil BTA-06007248 6K Aluminum Dockboard (72in. Wide x 48in. Long) Specs
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 130.0 lbs |
| Capacity | 6,000 lb |
| Ramp Length | 48 in |
| Ramp Width | 72 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.313 in |
| Left Leg Height | 8 in |
| Right Leg Height | 9 in |
| Height Difference | 5.5 in |
| Usable Ramp Length | 48 in |
| Usable Ramp Width | 67.5 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 130.0000 lb |
| Dimensions L x W x H (in.) | 48.0 x 72.0 x 11.75 in |
