Prince Welded Tee Hydraulic Cylinder 4in. Bore x 48in. Stroke 2500 PSI
The Prince Welded Tee Hydraulic Cylinder is a robust, single-piece solution for high-force applications. With a 4-inch Bore and a long 48-inch Stroke, this cylinder handles demanding tasks up to 2500 PSI. The Welded Tee construction provides superior strength and durability, making the Prince Hydraulic Cylinder ideal for use in loaders, agricultural equipment, and industrial machinery.
Description
Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting.
What’s Included
- (1) Welded tee cylinder
| Item# | 905648 |
| Brand | Prince |
| Manufacturer’s Warranty | 3 year limited warranty |
| Ship Weight | 100.0 lbs |
| Max. PSI | 2,500 |
| Bore Diameter | 4 |
| Stroke Length | 48 |
| Shaft Diameter | 2 |
| Closed Pin Center | 58 |
Prince 4in. Bore x 48in. Stroke Welded Tee Cylinder Specs
| Brand | Prince |
| Full Model Code | 905648 |
| Country of Origin | USA |
| Tool Category | Welded Cross-Tube Hydraulic Cylinder |
| Action Type | Double Acting |
| Maximum Operating Pressure | 2,500 PSI (5,000 PSI Burst) |
| Stroke / Travel | 48 inches |
| Collapsed Height | 58 inches (Closed Pin Center) |
| Cylinder Bore Diameter | 4 inches |
| Plunger Diameter | 2 inch Shaft / 1.25 inch Pin Hole |
| Material | All Steel Welded Construction |
| Coupler Type | 1/2 in Working Ports |
| Standard Warranty | 3 year limited warranty |
| Product Weight | 100 lbs (45.36 kg) |
| Application | Contractor and industrial use with universal cross-tube end mountings. |
