JET GH-1860ZX ZX Geared Head Lathe – 18in x 60in
$12,677.00
In Stock
In Stock
2-Day Shipping
All orders are processed and dispatched within 2 days
Description
This JET ZX Series Large Spindle Bore Geared Head Lathe provides power, precision, efficiency and reliability to any metal shop. A 1-piece cast iron base absorbs vibrations during operation to allow heavier cuts and ensure accuracy, while the universal gearbox eliminates the need to change gears. 18in. swing over bed, 27 1/2in. swing through gap, 60in. distance between centers, 3 1/8in. spindle bore, 7 1/2 HP, 230/460V, 3-phase motor. Loaded with features and backed by an industry-leading 2-year limited warranty.
What’s Included
- (1) Large spindle bore geared head lathe
| Item# | 71308 |
| Brand | Jet |
| Manufacturer’s Warranty | 24 months parts / 24 months labor |
| Ship Weight | 6316.0 lbs |
| Distance Between Centers (in.) | 60 |
| Swing Over Bed (in.) | 18 |
| Volts | 230/460 |
| Horsepower | 7.5 |
| Speed (RPM) | 25–1,800 |
| Spindle Bore (in.) | 3 1/8 |
| Spindle Mount | D1-8 |
| Carriage Travel (in.) | 55 9/16 |
| Thread Cutting (in.) | 1 5/8-72 |
| Thread Cutting (mm) | 0.05–20 |
| Stand Included | Yes |
| Dimensions L x W x H (in.) | 115 x 44 x 66 in |
| Product Weight | 6,245 lb |
JET GH-1860ZX ZX Geared Head Lathe Specs
| Brand | JET |
| Full Model Code | GH-1860ZX (Geared Head) |
| Country of Origin | Taiwan |
| Lathe Type | Geared Head Metal Lathe |
| Swing Over Bed | 18 inches |
| Swing Through Gap | 27-1/2 inches |
| Distance Between Centers | 60 inches |
| Spindle Bore | 3-1/8 inches |
| Spindle Taper | D1-8 Mount |
| Spindle Speed Range | 25–1,800 RPM |
| Motor Power | 7.5 HP |
| Electrical Requirement | 230/460 Volts (3-Phase) |
| Base Construction | 1-Piece Cast Iron Vibration-Absorbing Base |
| Product Weight | 6,245 lbs (2,832.68 kg) |
| Machine Dimensions | 115 x 44 x 66 in |
| Application | High-reliability shop operation allowing heavier cuts with increased accuracy via vibration-absorbing base. |
