Jenny K15A-30 Air Compressor – 1.5HP 30Gal
Reliable Motor Performance: Delivers steady 1.5 HP output
Horizontal Receiver Design: Features 30-gallon stationary tank capacity
Standard Electrical Phase: Requires 115V single-phase electrical supply
Maximum Working Pressure: Maintains stable 125 PSI delivery
Rugged Material Durability: Includes durable cast iron pump components
Description
Jenny K15A-30 1.5HP 30 Gallon Compressor
The Jenny K15A-30 is a versatile stationary air compressor that combines a reliable 1.5HP electric motor with a substantial 30-gallon air reserve. This model is engineered to provide a stable pressurized environment for professional workshops, balancing a manageable footprint with enough storage capacity to support multiple pneumatic tools without the frequent motor cycling found in smaller portable units.
Mechanical efficiency is optimized by a belt-driven single-stage pump that operates at a lower RPM to reduce heat and noise. Relying on industrial reciprocating air compressors from Jenny’s K-series ensures your shop maintains a steady 6.2 CFM delivery, backed by an ASME certified tank for long-term operational safety and durability.
Jenny K15A-30 Key Features
- Tank Size: 30 Gallon Horizontal
- Lubrication: Splash Lubrication Pump
- Starting System: Automatic Pressure Switch
- Fuel System: 115/230V Single Phase
- Max Pressure: 125 PSI Rating
- Air Displacement: 6.2 CFM Delivery
- Warranty: 1 Year Warranty
ASME Certified Steel Receiver
The 30-gallon horizontal tank is powder-coated and manufactured in the USA to meet strict ASME safety standards for pressure vessels. It features a manual tank drain for easy moisture management and a high-quality safety relief valve to protect the system. This structural integrity ensures the unit can handle the high-pressure demands of professional automotive and woodworking shops.
Professional Shop and Maintenance
Ideally suited for automotive repair bays, small manufacturing cells, and technical educational facilities, this unit provides a dependable stationary air source. The K15A-30 is valued for its quiet operation and the consistent recovery times provided by its twin-cylinder cast iron pump. Its horizontal orientation allows it to be placed under workbenches to maximize available floor space.
Trust the Jenny K15A-30 to provide a stable and efficient air solution for your specialized technical workshop or facility. Contact our technical team to Request Technical Quote or Check Availability at Muldepot.com.
Jenny K15A-30 Air Compressor Specs
| Brand | Jenny |
| Full Model Code | K15A-30 |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Single-Stage) |
| Lubrication Style | Splash Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 1.5 HP |
| Max Working Pressure | 125 Psi |
| Free Air Delivery / Capacity | 6.2 CFM @ 100 Psi |
| Drive Type | Belt Drive (Electric) |
| Noise Level | 74-76 dB(A) |
| Outlet Connection Size | 1/2 Inch NPT |
| Tank Volume | 30 Gallons (Horizontal) |
| Dimension (LxWxH) | 965 x 406 x 737 mm |
| Net Weight | 88 kg |
| Control Panel Type | Pressure Switch Controlled |
| Voltage/Phase/Frequency | 115-230V / 1 Phase / 60 Hz |
| Standard Warranty | 1 Year Limited |
| Maintenance Interval | 500 Hours |
| Application | Industrial maintenance and stationary shop use requiring higher air volume on standard single-phase circuits. |
