Jenny F34A-17 Air Compressor – 0.75HP 17Gal
Enhanced Motor Strength: Supplies reliable 0.75 HP performance
Vertical Receiver Design: Features 17-gallon stationary tank capacity
Standard Electrical Phase: Requires 115V single-phase electrical supply
Maximum Sustained Pressure: Maintains consistent 125 PSI delivery
Rugged Material Durability: Includes durable cast iron pump components
Description
Jenny F34A-17 0.75HP 17 Gallon Compressor
The Jenny F34A-17 is a precision-engineered stationary air compressor designed for technical applications requiring consistent low-volume airflow and reliable storage. This 17-gallon unit features a 0.75HP industrial-grade motor and an American-made cast iron pump, providing a steady 3.1 CFM at 125 PSI for laboratories, medical facilities, and small-scale pneumatic control systems requiring a high-quality, long-lasting air source.
Mechanical reliability is enhanced by a belt-driven configuration and a large cooling flywheel that reduces operational temperatures. Utilizing industrial reciprocating air compressors like the F-series ensures superior volumetric efficiency, while the ASME certified powder-coated tank provides a safe and durable pressure vessel for sensitive professional environments.
Jenny F34A-17 Key Features
- Tank Size: 17 Gallon Horizontal
- Lubrication: Splash Lubrication System
- Starting System: Pressure Switch Control
- Fuel System: 115V Single Phase
- Max Pressure: 125 PSI Rating
- Air Displacement: 5.3 CFM Delivery
- Warranty: 1 Year Unit
Heavy Duty Cast Iron
The unit features a 100% cast iron pump housing to ensure maximum thermal stability and extended service life. This material selection provides excellent vibration dampening and protects internal moving parts from mechanical fatigue during frequent cycling. Precision-honed cylinders and stainless steel valves further contribute to the long-term reliability of the overall compression system.
Laboratory and Instrument Air
This model is perfectly suited for temperature control systems, dental labs, and specialized laboratory automation. The 17-gallon tank provides an ample buffer for intermittent tool use while the low-RPM pump ensures relatively quiet operation. Maintenance is streamlined via easy-access oil ports and a replaceable canister-style intake filter that protects the pump from fine particulates.
Trust the Jenny F34A-17 to provide a stable and efficient 0.75HP air solution for your specialized technical workspace. Contact our technical team to Request Technical Quote or Check Availability at Muldepot.com.
Jenny F34A-17 Air Compressor Specs
| Brand | Jenny |
| Full Model Code | F34A-17 |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Single-Stage) |
| Lubrication Style | Splash Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 0.75 HP |
| Max Working Pressure | 125 Psi |
| Free Air Delivery / Capacity | 3.1 CFM @ 100 Psi |
| Drive Type | Belt Drive (Electric) |
| Noise Level | 70-74 dB(A) |
| Outlet Connection Size | 1/4 Inch NPT |
| Tank Volume | 17 Gallons (Horizontal) |
| Dimension (LxWxH) | 864 x 356 x 660 mm |
| Net Weight | 65 kg |
| Control Panel Type | Pressure Switch Controlled |
| Voltage/Phase/Frequency | 115-230V / 1 Phase / 60 Hz |
| Standard Warranty | 1 Year Limited |
| Maintenance Interval | 500 Hours |
| Application | Mobile service applications and small maintenance facilities needing integrated tank storage. |
