Haldex 1400028 AC Hydraulic Power System 2 HP 115/230V AC Self-Contained
The Haldex 1400028 AC Hydraulic Power System offers versatile, dependable hydraulic power in a compact package. This Self-Contained unit features a 2 HP motor that can run on standard 115V or 230V AC power, making it flexible for various shop environments. The Haldex Power System is ideal for small hoists, lifts, and moderate-duty shop machinery.
Description
Handles a wide variety of industrial applications. All models have 1,725 RPM TEFC (totally enclosed, fan-cooled) motors, check valve, adjustable relief valve and 3,000 PSI pressure gauge. High-strength cast iron housing. DU bearings. Filler screen, sight gauge and flexible coupling. Hardened and ground alloy steel gears and shafts. Pressure-balanced pumps provide up to 90% overall efficiency. Ideal for systems using low-viscosity fluids in high temps and high-duty cycle applications. Does not include manifold or interface.
| Item# | 10591 |
| Brand | Haldex |
| Manufacturer’s Warranty | 1 year Limited Warranty |
| Ship Weight | 107.0 lbs |
| Flow (GPM) | 1.5 |
| Inlet Port (in.) | 9/16-18 SAE |
| Outlet Port (in.) | 9/16-18 SAE |
| Reservoir Capacity | 5 gal. |
| Volts | 115, 230 AC |
| Phase | 1 |
Haldex 1400028 AC Hydraulic Power System Specs
| Brand | Haldex |
| Full Model Code | 1400028 (Item# 10591) |
| Country of Origin | USA |
| Tool Category | Self-Contained AC Hydraulic Power System |
| Maximum Operating Pressure | 3,000 PSI Gauge Included |
| Capacity Class | 1.5 GPM Flow Rate |
| Oil Capacity | 5 Gallons |
| Material | Cast Iron Housing / Hardened Steel Gears |
| Coupler Type | 9/16-18 SAE Ports |
| Standard Warranty | 1 year limited warranty |
| Product Weight | 107 lbs (48.53 kg) |
| Application | Industrial applications requiring low-viscosity fluids and high duty cycles at 115/230V AC. |
