Fostoria by TPI FSP-9524-3 Portable Electric Heater 9.5kW 240V 32,414 BTU
Fostoria by TPI FSP-9524-3 delivers intense localized spot heating within uninsulated drafty workspaces, keeping industrial warehouse crews warm and productive during severe winter conditions.
- 32414 BTU outputs warm 500 sqft
- 9.5kW infrared elements heat objects directly
- Convertible 240V circuits match factory grids
- Gold anodized housings reflect energy efficiently
- Wheeled service carts provide effortless mobility
Description
Fostoria FSP-9524-3 Industrial Radiant Heater
Fostoria FSP-9524-3 portable flat panel unit provides immediate relief to warehouses and manufacturing facilities battling freezing ambient workplace zones. Delivering a powerful 32,414 BTU hourly heat output, this radiant heater comfortably warms workers and nearby machinery across 400 square feet without losing efficiency in drafts. Because it converts 240 volts of electricity with 78.5% efficiency, businesses drastically cut down on utility expenses while establishing consistent spot heating in high-bay steel mills.
Constructed with gold anodized aluminum housing and protective wire guards, the rugged element completely lacks breakable glass components to survive harsh physical impacts. The 60-pound unit includes a durable wheeled cart measuring 17.5 by 20 by 53 inches, allowing crews to roll 9,500 watts of heating power across rough shop floors. Running at 22.9 amps, the electrical system converts easily between 3-phase and single-phase power configurations to fulfill diverse industrial wiring needs.
Performance Metrics and Technical Data
- Generates 32,414 BTU per hour radiant output
- Covers 400 square feet heating range comfortably
- Consumes 9,500 watts of clean electrical energy
- Operates smoothly at 240 volts input capacity
- Draws 22.9 amps current on industrial lines
- Features 60 degree symmetrical infrared heat distribution
- Weighs 60 pounds total including mobile carriage
- Measures 17.5x20x53 inches for space saving storage
- Glass free elements ensure 25,000 hour lifespans
- Converts easily between single and three phase
Fostoria FSP-9524-3 Portable Infrared Electric Heater 9.5kW Specs
| Item# | 52488 |
|---|---|
| Brand | TPI (Fostoria) |
| Heat Type | Infrared / Radiant |
| Heat Output | 32,414 BTU/hr |
| Power Output | 9,500 Watts (9.5kW) |
| Voltage | 240V (3-Phase Convertible to Single Phase) |
| Heating Capability | 400 - 500 sq. ft. |
| Efficiency | 78.5% |
| Safety Features | Gold Anodized Housing, Protected Guards, No-Glass Elements |
| Operational Features | 60° Symmetrical Heat Distribution, Overhead Warming Ready, Element Life (25,000 hrs) |
| What's Included | (1) Heater, (1) Wheeled cart |
| Dimensions | 17.5 x 20 x 53 in. |
| Ship Weight | 60.0 lbs |
| Standard Warranty | 1-Year Limited Warranty |
