EMAX ESP10A080V3 – 3PH Vertical Solo Mount Silent Air Compressor

Description

Emax ESP10A080V3 | 76 CFM at 90 PSI Industrial Delivery Analysis

The Emax ESP10A080V3 is a high-efficiency three-phase vertical solo mount compressor engineered for modern manufacturing plants requiring maximum airflow and energy efficiency. Providing 76 CFM at 90 PSI, this unit ensures optimal pneumatic performance for automated production lines, utilizing its 80-gallon reservoir and dual-stage pump to maintain rapid recovery times under heavy industrial loads.

This smart air system incorporates pressure lubrication and an automatic electronic drain valve to sustain an 80% duty cycle. Because this model does not include a low oil shutdown feature, technical maintenance teams must perform regular oil audits to prevent terminal friction damage and maintain optimal pump longevity while operating on high-torque 230/460V electrical configurations.

Key Features: Emax ESP10A080V3

• Potent 10HP motor produces 76 CFM at 90 PSI.
• Vertical 80-gallon tank orientation saves critical industrial floor space.
• Quiet 67 dB noise level enhances the worker environment.
• Pressure lubrication system protects internal pump components under load.
• Electronic automatic drain valve ensures efficient moisture evacuation.
• Three-phase 230/460V power optimizes industrial electrical consumption.
• Cast iron pump material provides exceptional heat dissipation qualities.
• Large 1 inch NPT air outlet handles high-volume airflow.
• Smart monitoring technology allows for real-time system performance tracking.
• Two-stage pump design enables versatile 175 Max PSI output.

Automated Production Line Power

Ideal for CNC clusters, robotic cells, and high-demand pneumatic systems. This model features a 1 year warranty for industrial peace of mind. Compare our vertical solo mount compressors to ensure your facility has the necessary SCFM for peak operations.
