Champion HDPL5-8K Air Compressor – 9HP Diesel PL
In Stock
$5,460.00
In Stock
Champion HDPL5-8K Air Compressor: Heavy-duty 9HP Kohler diesel system featuring an 80-gallon tank and PL-Series pressure-lubricated pump, designed for high-capacity mobile service and industrial field work.
- Engine Specs: 9.8 HP Kohler Diesel
- Pneumatic Supply: 614 L/min (21.7 CFM)
- Maximum Force: 175 PSI (12 Bar)
- Tank Dimension: 80 Gallon Horizontal
- Technical Spec: Pressure Lubricated PL-15 Pump
Description
Champion HDPL5-8K Air Compressor – 9HP Diesel PL
The Champion HDPL5-8K Air Compressor – 9HP Diesel PL is engineered to eliminate operational downtime in remote environments where electrical grid access is unavailable. Unlike standard portable units, this high-performance system provides a ruggedized solution for heavy-duty field service, ensuring consistent pneumatic power for high-demand industrial tools under extreme thermal stress.
This unit is powered by a high-torque 9HP diesel engine, specifically integrated to maintain high volumetric efficiency during continuous 100% duty cycle operations. By utilizing heavy-duty diesel air compressors from Muldepot, operators gain access to a pressure-lubricated pump design that significantly reduces internal friction and extends the lifecycle of critical reciprocating components.
Champion HDPL5-8K Key Features
- Tank Size: 30 Gallon ASME Receiver.
- Lubrication: Pressure Lubricated PL Pump.
- Starting System: 12V Electric Start Integrated.
- Fuel System: Diesel Driven Power Plant.
- Max Pressure: 175 PSI High Output.
- Air Displacement: 23.2 CFM Performance Rating.
- Warranty: 2-Year Limited Pump Protection.
Spheroidal Graphite Cast Iron
This metallurgical core provides superior vibration damping and fatigue resistance compared to standard grey iron. Swedish steel reed valves maintain high-tension sealing under extreme thermal loads, preventing carbon build-up. An internal oil pump ensures all critical friction points receive consistent lubrication, allowing the pump to sustain high-pressure output without premature wear.
Mobile Field Service Applications
This diesel unit is purpose-built for remote mining and agricultural maintenance where electrical grid access is unavailable. It delivers the necessary high-flow CFM for heavy-duty pneumatic 1-inch impact wrenches and industrial grinders. To maintain peak reliability, replace the pressurized oil filter every 500 hours and inspect intake filters weekly for consistent off-grid performance.
The Champion HDPL5-8K Air Compressor – 9HP Diesel PL represents the pinnacle of mobile pneumatic engineering. Request a technical quote or verify current unit availability at Muldepot.com.
Champion HDPL5-8K Air Compressor Specs
| Brand | Champion |
|---|---|
| Full Model Code | HDPL5-8K (PL-Series) |
| Country of Origin | USA |
| Compressor Type | Reciprocating Piston (Two-Stage) |
| Lubrication Style | Pressure Lubricated |
| Cooling System | Air Cooled |
| Motor Power | 9.1 HP |
| Max Working Pressure | 175 Psi |
| Free Air Delivery / Capacity | 23.2 CFM @ 175 Psi |
| Drive Type | Belt Drive (Diesel Engine - Yanmar L100V) |
| Noise Level | 86-90 dB(A) |
| Outlet Connection Size | 3/4 Inch NPT |
| Tank Volume | 80 Gallons (Horizontal) |
| Dimension (LxWxH) | 1600 x 610 x 1143 mm |
| Net Weight | 335 kg |
| Control Panel Type | Engine Mounted Controls / Pressure Monitor |
| Voltage/Phase/Frequency | N/A (Diesel - 12V DC Start) |
| Standard Warranty | 5 Year Pump / 1 Year Unit |
| Maintenance Interval | 1000 Hours |
| Application | Industrial remote field maintenance requiring the ultimate pump protection via pressure lubrication. |
