Briggs Stratton 19L232 – 205cc Horizontal Engine
In Stock
$474.00
In Stock
Power your commercial-grade equipment with the Briggs & Stratton 19L232 Engine featuring a 205cc displacement and overhead valve technology for industrial torque.
- Power: 205cc Professional Series Engine
- Torque: 11.5 Gross Torque Rating
- Shaft: One Inch Keyed Shaft
- Lubrication: Industrial Grade Splash System
- Warranty: Two Year Limited Warranty
Description
Professional Coffee Equipment
Briggs Stratton 19L232 0037 F1 Horizontal Engine
Briggs Stratton 19L232-0037-F1 horizontal Vanguard engine is 305cc and puts out 10.0 HP (maximum horsepower). This single-cylinder Vanguard has a 1" x 3-21/32" crankshaft with a 1/4" keyway.| BRAND | Briggs Stratton |
|---|---|
| MODEL NUMBER | 19L232-0037-F1 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 66 |
| DISPLACEMENT | 305cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Horizontal |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 1" x 3-21/32" |
| CRANKSHAFT LENGTH | 3-21/32" |
| CRANKSHAFT END TAPPED SIZE | 7/16 - 20 |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| BEARING TYPE | Dual Ball |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron Sleeve |
| AIR CLEANER TYPE | Cartridge with Pre Filter |
| FUEL TANK | Yes |
| FUEL PUMP | No |
| OIL COOLER | No |
| OIL CAPACITY | 28 |
| LOW OIL ALERT | Yes |
| LOW OIL SHUTDOWN | No |
| IGNITION SYSTEM | Electronic |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Manual |
| MAX RPM | 3600 |
| CHARGING SYSTEM | None |
| BOLT CIRCLE | 3-5/8", 5, 6-1/2 |
| FLYWHEEL | Heavy |
| PTO HEIGHT | 4 - 11/64 |
