BelAire 338VL Air Compressor – 10HP Quiet

BelAire 338VL Air Compressor: 9.5-HP Kohler-Powered Vertical Industrial Series

The BelAire 338VL Air Compressor is a specialized, gasoline-driven pneumatic solution engineered for mobile contractors and service technicians who need to maximize tool storage without sacrificing air power. By mounting the industrial-grade 9.5-HP Kohler CH395 Command Pro engine on a high-capacity 30-gallon vertical ASME receiver, this space-saving vertical powerhouse provides a high-pressure independent air source that utilizes a minimal footprint. Investing in the 338VL through our platform ensures a rugged independent air infrastructure, ideal for crowded service truck beds, tire repair rigs, and remote job sites where floor space is at a premium.

At its engineering core, the 338VL features a heavy-duty two-stage solid cast iron pump delivering a formidable 19.1 CFM at 100 PSI and 17.5 CFM at 175 PSI. As a key entry in our professional gas-powered air compressor collection, it utilizes Kohler’s Quad-Clean™ four-stage cyclonic air filtration system. This configuration ensures peak volumetric efficiency even in extremely dusty field environments, utilizing a centrifugal unloader to facilitate loadless starts that protect the engine’s drivetrain and ensure 100% industrial duty cycle reliability.

Technical Engineering Specifications

• Engine Power: 9.5-HP Kohler CH395 Command Pro (Recoil Start).
• Pump Design: Two-Stage Solid Cast Iron for 100% Industrial Duty Cycle.
• Performance: 19.1 CFM @ 100 PSI / 17.5 CFM @ 175 PSI.
• Tank Configuration: 30-Gallon Vertical ASME Certified & Coded Receiver.
• Filtration: Quad-Clean™ Four-Stage Cyclonic Air Filter.
• Max Pressure: 175 PSI (Optimized for High-Torque Pneumatic Tools).
• Valving: Stainless Steel Disc Valves for Longevity and Flow.
• Warranty: 2-Year Factory-Backed Pump Protection.

“The 338VL is a game-changer for our mobile fleet. The vertical tank allows us to fit a full-power industrial compressor into the corner of the service bed, leaving plenty of room for our parts bins. The Kohler engine starts first pull every time, even in the cold.”

Advanced Durability & Lifecycle Architecture

Designed for long-term operational ROI in the field, the BelAire 338VL eliminates mechanical fatigue through precision engineering and industrial-grade materials:

• Solid Cast Iron Architecture: Pump cylinders and heads are built from 100% cast iron to provide superior thermal stability and prevent warping under continuous high-pressure loads.
• Quad-Clean™ Technology: The Kohler engine features an all-weather cyclonic filtration system that spins out dust and debris before it hits the filter, significantly extending engine life.
• Precision-Balanced Drivetrain: Features a dynamically balanced crankshaft that minimizes harmonic vibration, protecting bearings and seals from premature wear.
• High-Efficiency Valving: Equipped with corrosion-resistant stainless steel disc valves for increased airflow and significantly longer service intervals than standard reed valves.
• ASME Certified Vessel: The 30-gallon vertical tank is heavy-gauge steel coded for safety in professional commercial and mobile industrial environments.

Operational Impact: Tool Compatibility & Application

The BelAire 338VL is optimized to power a wide range of high-demand pneumatic equipment on the move:

• Mobile Repair Services: Provides the volume needed for 3/4-inch Pneumatic Impact Wrenches and high-torque air jacks.
• Contracting & Framing: Easily supports multiple Framing Nailers or large pneumatic staplers simultaneously in remote areas.
• Agricultural Maintenance: Ideal for Pneumatic Greasing Systems and inflating large tractor tires on-site without electrical access.

Maximize your mobile field productivity with the BelAire 338VL Air Compressor and experience the perfect balance of vertical space-saving design and Kohler-driven reliability. Order from Muldepot.com today to benefit from specialized industrial shipping and the expert technical support required for your mobile air infrastructure. Don’t compromise on floor space—invest in the durable vertical architecture of BelAire today.
