Vestil BTA-20007860 20K Aluminum Dockboard (78in. Wide x 60in. Long)
In Stock
$1,289.00
In Stock
Vestil BTA-20007860 20K Aluminum Dockboard provides a 20,000lb capacity in a 78-inch wide by 60-inch long size, a versatile heavy-duty choice.
- Reliable 20,000lb Weight Limit: Specifically built for high-capacity forklift transit across standard gaps.
- Optimized 78″ Width: Accommodates standard trailers with ease while providing ample wheel clearance.
- Integrated Safety Legs: Keeps the board securely anchored to the dock for maximum safety.
- Zinc-Plated Hardware: Durable components ensure the dockboard remains reliable and stationary during use.
- Smooth Beveled Edges: Designed to minimize jarring during wheel transitions for safer heavy loading.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operat aions. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at a least four times the lifting capacity of fork truck. The width of the dockboard should be at a least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 78 X 60 and usable dimenions of 72-1/4 X 59-3/4. This dockboard is rated at a 20000 lbs. capacity.
| Item# | 4223210 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 326.0 lbs |
| Capacity | 20,000 lb |
| Ramp Length | 60 in |
| Ramp Width | 78 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.625 in |
| Left Leg Height | 11 in |
| Right Leg Height | 13 in |
| Height Difference | 7 in |
| Usable Ramp Length | 59.75 in |
| Usable Ramp Width | 72.25 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 326.0000 lb |
| Dimensions L x W x H (in.) | 60.0 x 78.0 x 0 in |
