Vestil BTA-08006666 8K Aluminum Dockboard (66in. Wide x 66in. Long)
In Stock
$1,701.00
In Stock
Vestil BTA-08006666 8K Aluminum Dockboard provides an 8,000lb capacity in a symmetrical 66-inch square format, ideal for balanced mid-sized loading.
- Professional 8,000lb Capacity: High-strength aluminum construction handles dense loads and equipment.
- Balanced 66″ x 66″ Size: Provides a square, stable footprint for standard dock-to-truck gaps.
- Safety Yellow Curbs: Improves awareness of the board edges and prevents steering errors.
- Locking Safety Pins/Legs: Essential for preventing the dockboard from moving during heavy usage.
- Smooth Beveled Edges: Facilitates easy entry and exit for wheels, protecting the load.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operations. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at least four times the lifting capacity of fork truck. The width of the dockboard should be at least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 66 X 66 and usable dimenions of 61-1/2 X 66. This dockboard is rated at a 8000 lbs. capacity.
| Item# | 4221134 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 235.0 lbs |
| Capacity | 8,000 lb |
| Ramp Length | 66 in |
| Ramp Width | 66 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.5 in |
| Left Leg Height | 12 in |
| Right Leg Height | 14 in |
| Height Difference | 8 in |
| Usable Ramp Length | 66 in |
| Usable Ramp Width | 61.5 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 235.0000 lb |
| Dimensions L x W x H (in.) | 66.0 x 66.0 x 15.75 in |
