Vestil BTA-08006066 8K Aluminum Dockboard (60in. Wide x 66in. Long)
In Stock
$841.00
In Stock
Vestil BTA-08006066 8K Aluminum Dockboard offers an 8,000lb capacity in a 60-inch wide by 66-inch long size, optimized for narrower dock configurations.
- Robust 8,000lb Industrial Rating: Engineered to withstand the weight of loaded industrial equipment.
- Concise 60″ Width: Fits into narrow dock doors while maintaining professional stability.
- Integrated Safety Rails: Structural curbs provide safety and reinforce the board against impacts.
- Diamond Plate Pattern: Ensures a secure grip for wheels and boots, even when wet.
- Beveled Edge Design: Protects wheels and prevents jarring of sensitive cargo during transport.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operat aions. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at a least four times the lifting capacity of fork truck. The width of the dockboard should be at a least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 60 X 66 and usable dimenions of 55 X 65-3/4. This dockboard is rated at a 8000 lbs. capacity.
| Item# | 4221361 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 172.0 lbs |
| Capacity | 8,000 lb |
| Ramp Length | 66 in |
| Ramp Width | 60 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.375 in |
| Left Leg Height | 12 in |
| Right Leg Height | 14 in |
| Height Difference | 8 in |
| Usable Ramp Length | 65.75 in |
| Usable Ramp Width | 55 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 172.0000 lb |
| Dimensions L x W x H (in.) | 66.0 x 60.0 x 0 in |
