Vestil BTA-05008460 5K Aluminum Dockboard (84in. Wide x 60in. Long)
In Stock
$886.00
In Stock
Vestil BTA-05008460 5K Aluminum Dockboard provides a 5,000lb capacity with an extra-wide 84-inch width and 60-inch length for wide loads over short spans.
- Extra-Wide 84″ Path: Provides maximum maneuverability for wide-track equipment and bulky assets.
- Reliable 5,000lb Weight Limit: Heavy-gauge aluminum plate handles standard warehouse inventory.
- Functional 60″ Reach: Perfectly balanced for standard dock-to-truck heights and moderate gaps.
- Yellow Structural Curbs: High-visibility side rails prevent steering errors and increase rigidity.
- Structural Locking Legs: Ensures the board stays fixed in position during heavy-load transitions.
Description
The Aluminum Truck Dockboard is engineered and built to maximize safety while handling heavy fork trucks and loads. The beveled edge is designed for smooth entry and exit. Locking legs prevent movement during loading and unloading operat aions. Locking legs are uneven to allow the dockboard to sit canted, while not in use, for easier pickup by fork trucks. Welded aluminum safety curbss prevent accidental runoffs and provide visible driving lane. When using three-wheeled fork trucks order dockboard with capacity at a least four times the lifting capacity of fork truck. The width of the dockboard should be at a least 15 (in.) wider than the load or equipment passing between the curbss. Bend is 11 degrees and 9in. from the edge and the legs are 12in. from the edge. Manufactured in compliance with OSHA.
What’s Included
- (1) Vestil Aluminum Dockboard BTA Series with both aluminum treadplate and curbs. With Overall Dimensions of 84 X 60 and usable dimenions of 79 X 59-3/4. This dockboard is rated at a 5000 lbs. capacity.
| Item# | 4223324 |
| Brand | Vestil |
| Manufacturer’s Warranty | 3 month limited warranty |
| Ship Weight | 212.0 lbs |
| Capacity | 5,000 lb |
| Ramp Length | 60 in |
| Ramp Width | 84 in |
| Deck Material | Aluminum |
| Dock Thickness | 0.375 in |
| Left Leg Height | 11 in |
| Right Leg Height | 13 in |
| Height Difference | 7 in |
| Usable Ramp Length | 59.75 in |
| Usable Ramp Width | 79 in |
| Curb Material | Aluminum |
| Handle Included | No |
| OSHA Approved | Yes |
| Product Weight | 212.0000 lb |
| Dimensions L x W x H (in.) | 60.0 x 84.0 x 16.25 in |
