Rolair H10360K50 Air Compressor – 10HP 60Gal
In Stock
$2,052.00
In Stock
Rolair H10360K50 Air Compressor is a 10 HP splash-lubricated 175 PSI horizontal unit featuring a 60-gallon tank for reliable single-phase industrial and automotive service.
Optimal Air Delivery: Supplies 34 CFM @175PSI.
Space Saving Horizontal: Features stable low-profile design.
Heavy Duty Construction: Guarantees long-term durability.
Single Phase Source: Operates on 230V.
Automotive Service Use: Powers professional pneumatic equipment.
Description
Rolair H10360K50 10HP 60 Gallon Horizontal Compressor
The Rolair H10360K50 is a high-output two-stage stationary compressor engineered for workshops requiring high-volume air delivery in a compact horizontal design. Driven by a 10HP three-phase motor on a 60-gallon ASME tank, it delivers a robust 32.4 CFM at 175 PSI, providing a reliable air source for heavy-duty impact tools and automated machinery in professional environments.
Thermal management is optimized through a two-cylinder pump design with a finned intercooler and an aluminum head for rapid cooling. Relying on industrial reciprocating air compressors like the H10 series ensures a stable and cool air supply, thanks to precision-machined cast-iron pump components that maintain peak volumetric performance during high-intensity operational cycles.
Rolair H10360K50 Key Features
- Tank Size: 60 Gallon Horizontal
- Lubrication: Splash Lubrication System
- Starting System: Pressure Switch Operation
- Fuel System: Three Phase Power
- Max Pressure: 175 PSI Rating
- Air Displacement: 32.4 CFM Delivery
- Warranty: 1 Year Warranty
Horizontal Stability and Recovery
The 60-gallon horizontal ASME tank offers a stable center of gravity for stationary shop placement and quick recovery times for air-hungry tools. It includes a heavy-duty brass shut-off valve, a 0-300 PSI pressure gauge, and an automatic unloading device for smooth operation. This model is preferred for installations where vertical height is limited but high air volume is required.
Professional Shop Maintenance
This model is the primary choice for automotive service bays and industrial shops that utilize air-intensive equipment. The 10HP motor ensures rapid tank refills, reducing downtime during peak demand periods. Technical users value the H10360K50 for its rugged cast-iron construction and the consistent high-pressure output provided by the reliable K50 series pump assembly.
Trust the Rolair H10360K50 to provide the high-performance air delivery and industrial durability your workshop demands. Contact our technical team to Request Technical Quote or Check Availability at Muldepot.com.
Rolair H10360K50 Air Compressor – 10HP, 60 Gallon Tank
| Weight | 635 lbs |
| Dimensions | 52 × 23 × 52 in |
| Brand | Rolair |
| Model | H10360K50 |
| Compressor CFM | 32.4 |
| Compressor CFM Range | 25 – 44.9 |
| Compressor Horsepower | 10 HP |
| Horsepower Range | 10 – 20 HP |
| Compressor Tank Size | 60 Gallon |
| Tank Size Range | 60-80 Gallon |
| Compressor PSI | 175 PSI |
| Voltage | 208/3/60, 230/3/60, 460/3/60 |
| Warranty | 1-Year |
