Quincy QP MAX 3103D12HCA46M – Pressure Lubricated Air Compressor
In Stock
$3,314.00
In Stock
Quincy QP MAX 3103D12HCA46M – Pressure Lubricated Air Compressor This industrial-scale 10 HP duplex unit features a high-voltage configuration with pressure-lubricated pumps designed to provide redundant air supply for high-demand manufacturing maintenance.
Redundant Power System: Dual high performance motor units
High Voltage Drive: Requires 460V three phase electrical
Massive Storage Capacity: Industrial 120 gallon horizontal tank
Active Oil Pressure: Integrated pump for internal lubrication
Rugged Facility Utility: Supports continuous heavy duty production
Quincy QP MAX 3103D12HCA46M Pressure-Lubricated Reciprocating Air Compressor
| Model | 3103D12HCA46M |
| Brand | Quincy |
| Manufacturer’s Warranty | 5-Year |
| Ship Weight | 3850.0 lbs |
| Horsepower | 10 |
| Air Tank Size | 120 |
| Volts | 460 |
| Stage | 2 |
| CFM at 90 PSI | 35.9 |
| Max. PSI | 175 |
| CFM at Max. PSI | 35 |
| Working Pressure | 175 |
| Air Outlet Size | 3/4 |
| Motor RPM | 1,750 |
| Motor Phase | 3 |
| Duty Cycle | 100 % |
| Pump Life | 60,000+ hr |
| Pump Material | Cast iron w/aluminum head |
| Oil Required | Yes |
| Low Oil Shutdown | Yes |
| Lubrication System | Pressure lube |
| Drain Type | Automatic |
| Weight (lbs.) | 865 |
| Dimensions L x W x H (in.) | 78 x 28 x 55 |
