Quincy QP MAX 3103D12HCA23M – Pressure Lubricated Air Compressor
In Stock
$3,314.00
In Stock
Quincy QP MAX 3103D12HCA23M – Pressure Lubricated Air Compressor This professional-grade 10 HP duplex system utilizes a massive horizontal configuration with magnetic starters built to deliver maximum air reserve stability for facilities.
Ultimate Piston Power: Powerful 10.0 HP total performance
Advanced Pressure Lubrication: Superior protection for rotating parts
Industrial Horizontal Tank: Features 120 gallon stationary receiver
Standard Three Phase: Requires 230V industrial power supply
Maximum Sustained Pressure: Maintains consistent 175 PSI delivery
Quincy QP MAX 3103D12HCA23M Pressure-Lubricated Reciprocating Air Compressor
| Model | 3103D12HCA23M |
| Brand | Quincy |
| Warranty | 5-year |
| Ship Weight | 850.0 lbs |
| Horsepower | 10 |
| Air Tank Size | 120 |
| Volts | 230 |
| Stage | 2 |
| CFM at 90 PSI | 35.9 |
| Max. PSI | 175 |
| CFM at Max. PSI | 35 |
| Working Pressure | 175 |
| Air Outlet Size | 3/4 |
| Motor RPM | 1,750 |
| Motor Phase | 3 |
| Duty Cycle | 100 % |
| Pump Life | 60,000+ hr |
| Pump Material | Cast iron w/aluminum head |
| Oil Required | Yes |
| Low Oil Shutdown | Yes |
| Lubrication System | Pressure lube |
| Drain Type | Automatic |
| Weight (lbs.) | 865 |
| Dimensions L x W x H (in.) | 78 x 28 x 55 |
